Description
Attention: It don't support annex B. ADSL2+ TLD801C Tester Features:
New Multi-functional TLD801C ADSL Tester ADSL2+ Tester DMM PING Test Meter
It supports the testing function such as parameter, error, DMM, PING that related to ADSL2+ service, user register authentication on the ADSL2+ user’s line side.
Attention: It don't support annex B.
1. Comply with multi-standards: ITU-T G.992.1 (G.DMT), ITU-T G.992.2 (G.Lite), ADSL2 (G.992.3), ADSL2+(G.992.5)
2. Automatically fit for the ADSL line standards, real-time display ADSL line connection status
3. Support both WAN PING and LAN PING
4. Support replacing MODEM and simulating the whole process of login on Internet
5. High resolution backlight large LCD, Handheld design and easy-to-use
6. Built-in Li rechargeable battery and smart charger circuit.
7. High storages capacity, can store up to 70 groups of test results including settings and results information.
8. Various Voice alarm and LED indications
9. Upgradeable software via an integrated RS-232 interface
10. Test results uploaded, conserved and printed by PCManager Software
ADSL2+ TLD801C Tester Testing data:
Basic:
Line standard,
Frame structure,
Line connection.
Parameter:
Fast Bit Rates (FAST): Upstream and Downstream;
Interleaved Bit Rate (INTL): Upstream and Downstream;
Max Bit Rate: Upstream and Downstream;
Utilize Rate: Upstream and Downstream;
Transmit Power: Upstream and Downstream;
Line Attenuation: Upstream and Downstream;
SNR Margin (Signal to Noise Ratio) : Upstream and Downstream;
Link:(Near and Far)
Loss of Power (LOP)
Loss of Signal (LOS)
Severe Error Frame (SEF)
Reed-Solomon Forward Error Corrections (FEC) INTL
Reed-Solomon Forward Error Corrections (FEC) FAST
Cyclic Redundancy Check (CRC) anomalies INTL
Cyclic Redundancy Check (CRC) anomalies FAST
No Cell Delineation (NCD) INTL
No Cell Delineation (NCD) FAST
Header Error Check (HEC) INTL
Header Error Check (HEC) FAST
Out of Cell Delineation (OCD) INTL
Out of Cell Delineation (OCD) FAST
Sever Error Second (SES)
Error Second (ES),
Bit Error (BE)
Alarm:
Downstream Transmit Speed Threshold
Downstream SNR Margin Threshold
Downstream Channel Threshold
Downstream Line Attenuation Threshold
Upstream Line Attenuation Threshold
DMT
SNR and Character bits allocation (graphic format) under 256/512 DMT
PING testing
WAN PING testing:IP or domain ping testing, statistic Percentage of PING packet loss
LAN PING testing:IP PING testing, Find out the faultily connected PC and statistic Percentage of PING packet loss
DMM (Optional)
AC, DC voltage
Loop feeding current
Round resistance
Line capacitance
Line insulation capacitance
Estimate line distance
Package including:
1pc x ADSL2+ TLD801C Tester
